| Place of Origin: | China |
| Brand Name: | Yinchen |
| Certification: | ISO SGS CE |
| Model Number: | WNS |
| Minimum Order Quantity: | 1set |
|---|---|
| Price: | 2500-8000USD |
| Packaging Details: | Export standard Ocean transport packing |
| Delivery Time: | 10-15 work days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 200 set per month |
| Name: | Industrial Steam Boiler | Material: | Boiler Special Steel Q245R |
|---|---|---|---|
| Color: | Customized | Usage: | All Kinds Of Industry |
| Shipping: | Ocean Or Railway | Fuel Type: | Oil,Gas |
| High Light: | propane fired steam boiler,oil fired condensing boilers |
||
Product introduction:
The boiler belongs to the furnace-down type internal combustion three-return wet-back type shell quick-loading boiler.
Boiler Feature:
The burner adopts the Italian Baltur imported burner, and the automatic control system is professionally manufactured by Nanjing Rentai Faen Electric Co., Ltd. Suitable for burning natural gas, liquefied gas, light oil and new alcohol-based fuels.
The diameter of the cylinder is large, the steam space is correspondingly large, and the steam quality is good and the load adaptability is strong.
The furnace adopts a high-efficiency, heat-strengthened threaded pipe; the three-pass design, long flue gas flow, low exhaust gas temperature and high thermal efficiency.
The fuel is ignited in the fire channel in front of the corrugated furnace. The high-temperature flue gas after combustion is diverted from the furnace to the flue pipe bundle and the front smoke box, and then passed through the pipe bundle into the rear smoke box and the chimney. atmosphere.
The boiler has the characteristics of simple manufacture, low steel consumption, small volume, high thermal efficiency, low pollution, low noise, convenient installation and high operation management efficiency.
Boiler parameter:
| Type | WNS0.5-1.0-Y(Q) | WNS1-1.0-Y(Q) | WNS2-1.0-Y(Q) | WNS3-1.25-Y(Q) | WNS4-1.25-Y(Q) | WNS6-1.25-Y(Q) | WNS8-1.25-Y(Q) | WNS10-1.25-Y(Q) |
|
Rated Output (t/h) |
0.5 | 1 | 2 | 3 | 4 | 6 | 8 | 10 |
|
Rated Steam Pressure (Mpa) |
1.0 | 1.0 | 1.25 | 1.25 | 1.25 | 1.25 | 1.25 | 1.25 |
|
Steam Temperature (℃) |
184 | 184 | 194 | 194 | 194 | 198 | 194 | 194 |
|
Thermal Efficiency (%) |
92.2 | 92.4 | 92.5 | 92.5 | 92.8 | 93.2 | 93.5 | 93.8 |
|
Power Consumption (Kw) |
2.96 (2.96) |
4.4/8.9 (3.7) |
7/20.2 (7) |
9.5/22.7 (10.5) |
13/26.2 (13.5) |
23/45.4 (20.5) |
24/37.5 (24) |
39.5/52 (39.5) |
| Suitable Fuel | Light Oil/ Heavy oil, Natural gas/ Town gas, Coke oven gas | |||||||
| Power Supply(AC) | 380V 50Hz | |||||||
Boiler usage:
The boiler can used to many industries,such as Beverage industry,Chemical industry,Food industry,Greenhouse heating,paper industry,Pharmaceutical industry,Rubber industry,Textile industry,Hotel,Rice mill industry,Garment industry,Asphalt industry etc.
