| Place of Origin: | China |
| Brand Name: | Yinchen |
| Certification: | ISO SGS CE GB |
| Model Number: | WNS |
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | 3000-89800 USD |
| Packaging Details: | Regular Package: boiler body and large auxiliary equipments (platform, chimney, economizer, etc ) are nude packed or tied up. |
| Delivery Time: | 1-20 working days |
| Payment Terms: | L/C, T/T, MoneyGram |
| Supply Ability: | 5000 set per year |
| Keywords: | Industrial Steam Boiler | Boiler Steel Plate: | Q245R,20g |
|---|---|---|---|
| Boiler Control: | Fully Automatic Control | Thermal Efficiency: | >93% |
| Type: | Natural Circulation | Steam Capacity: | 0.5t/h---20t/h |
| Pressure: | 0.7Mpa 1.0Mpa 1.25Mpa Or Other | Feed Water Temperature: | 20C Or 105C |
| High Light: | oil fired condensing boilers,3 pass fire tube boiler |
||
Boiler brief introduction:
WNS series automatic Oil&Gas-fired boiler is horizontal, three-pass, wet back shell boiler. The main parts include: Boiler shell, Corrugated furnace, Reversal chamber, Threaded smoke pipe, etc.
Burner: The boilers are matched with imported burner of Famous international brand. Proportional control. With procedure ignition, automatically blowing and flame-out protective device. And it has many merits such as good burning effect, reliability of ignition, burning rapidly, mix evenly of air and gas and adjusting scale of fuel gas and air. The burning efficiency is over 99.5%.
| Model | Rated | Rated | Rated | Thermal |
Fuel Consumption |
Equipment Power |
Weight | ||
|
Capacity (t/h) |
Pressure (Mpa) |
Temperature (C) |
Efficiency (%) |
Light oil (Kg/h) |
Natural gas (Nm³/h) |
Oil boiler |
Gas boiler | (t) | |
| WNS1 | 1 | 0.7/1.0/1.25 | 170/184/194 | >90 | 45-100 | 18-100 | 1.5 | 1.5 | 4 |
| WNS2 | 2 | 1.0/1.25/1.6 | 184/194/204 | >90.2 | 137.09 | 165.97 | 2.2 | 3 | 8 |
| WNS3 | 3 | >91 | 205.75 | 249.6 | 7.5 | 7.5 | 9 | ||
| WNS4 | 4 | >91 | 272.3 | 329.5 | 9 | 7.5 | 13 | ||
| WNS5 | 5 | >91.5 | 134-402 | 80-500 | 15 | 15 | 15 | ||
| WNS6 | 6 | >91.5 | 134-402 | 80-500 | 17.2 | 15 | 17 | ||
| WN8 | 8 | 1.25/1.6/2.5 | 194/204/225 | >91.6 | 523.4 | 631.5 | 26 | 22 | 21 |
| WNS10 | 10 | >91.6 | 212-890 | 150-1085 | 26 | 22 | 22 | ||
| WNS12 | 12 | >91.8 | 915.5 | 1090 | 26 | 22 | 27 | ||
| WNS15 | 15 | >91.8 | 931.5 | 1094.4 | / | / | 34 | ||
| WNS20 | 20 | >92 | 1380.33 | 1598.44 | / | / | 45 | ||
| Note: This Parameter just for reference only, we can design and production as per customers’ requirements. | |||||||||
Company introduction:
The boiler can used to many industries,such as Beverage industry,Chemical industry,Food industry,Greenhouse heating,paper industry,Pharmaceutical industry,Rubber industry,Textile industry,Hotel,Rice mill industry,Garment industry,Asphalt industry etc.
Why choose our boiler?
1. Lower dust emission & SO2 emission & NOx emission, dust emission concentration < 30mg/m³, SO2 & NOx emission concentration < 30mg/m³.
2. We have strict quality control system. From the material, welding, to finished boiler shipment, from project , establishment, drawing design, to final audit.
3. Each boiler system part is from first class brand all over the world or China, ensure the high quality.
4. We can offer the best after sales services and send our engineer to your factory to give you the complete installation and commission guidance.
Q1: How do you get the price?
First,You can tell us the boiler capacity, the fuel or pressure. Or tell us your configuration requirement.
Q2: Why do you choose us?
(1). Strength calculation report with applied materials information;
(2). 100%NDT(non-destructive inspection) report of steel plate, tube and welding rod;
(3). 100% X-ray inspection(welding seam): ensure the quality of entire boiler;
(4). Hydrostatic test ensure the standard working pressure and safety;
(5). Third-party inspection report:By Henan Boiler Inspection Institute;
(6). Passed ISO:9001 and SGS certificate.
Q3: What about the installation and Commissioning?
After you receive the boiler, we will guide you to make some preparation for installation;If necessary, our expert will fly to your place in 72 hours. The experts will responsible for guiding installation and commissioning.
Q4:What is the using life of your boiler?
A:Normally the boiler is designed for 20 years life span, but with right operation and good maintenance,you can use 20-25 years.
