Small Size Gas Fired Hot Water Boiler / Fire Tube Boiler And Water Tube Boiler

Small Size Gas Fired Hot Water Boiler / Fire Tube Boiler And Water Tube Boiler

    • Small Size Gas Fired Hot Water Boiler / Fire Tube Boiler And Water Tube Boiler
    • Small Size Gas Fired Hot Water Boiler / Fire Tube Boiler And Water Tube Boiler
  • Small Size Gas Fired Hot Water Boiler / Fire Tube Boiler And Water Tube Boiler

    Product Details:

    Place of Origin: HENAN
    Brand Name: Yinchen
    Certification: ISO SGS CE
    Model Number: ZWNS

    Payment & Shipping Terms:

    Minimum Order Quantity: 1
    Price: usd 5000-59800 set
    Packaging Details: 1.Package: Regular package or nut package; 2.Transportation: By land or by sea , it depends on the exporting areas.
    Delivery Time: 1-20 working days
    Payment Terms: L/C, T/T, MoneyGram
    Supply Ability: 5000 set month
    Contact Now
    Detailed Product Description
    Product Name: China Boiler Manufacturer ZWNS Type Fire Tube Gas Fired Water Boiler Structure Mode: Fire Tube
    Type: Horizontal Fuel: Gas, Oil. Etc
    Application Places: Hotels,District Heating,Office Buildings,Swimming Pool,School,Etc Output: Hot Water Boiler
    Range Of Output Power(Kal/H): 100000Kal/H~1200*10^4Kal/H Rated Output: 0.1- 20 Tons
    High Light:

    low pressure steam boiler

    ,

    fire tube steam boiler

    china boiler manufacturer ZWNS type fire tube gas fired water boiler



    Hot water boiler Introduction



    Hot water boilers include electric hot water boilers, oil-fired hot water boilers, gas-fired hot water boilers and coal-fired hot water boilers, etc. Hot water boilers are the boilers that produce hot water, referring to the use of fuel combustion to release heat or other heat energy (such as electricity, solar energy, etc.) to heat water to the rated temperature of a thermal equipment. The boiler defined in the Regulations on Safety Supervision of Special Equipment of China refers to the equipment that uses various fuels, electricity or other energy sources to heat the liquid filled to a certain parameter and output heat energy. The scope is defined as a pressurized steam boiler with a volume greater than or equal to 30L, and a pressurized hot water boiler with an outlet water pressure greater than or equal to 0.1MPa (meter pressure) and a rated power greater than or equal to 0.1Mw.



    Hot water boiler parameters:



    Type

    Rated Supply Heat

    (Kcal/h)

    Supply Power

    (V/Hz)

    Power Distribution

    (Kw)

    Natural Gas Consumption

    (Nm³/h)

    Light Oil

    Consumption

    (Kg/h)

    Flue Diameter

    (mm)

    Weight

    (T)

    ZWNS-10 10×104 220/50 0.25 12.3 10.5 DN100 0.9
    ZWNS-15 15×104 220/50 0.25 18.5 15.7 DN150 1.4
    ZWNS-20 20×104 220/50 043 24.7 20.9 DN150 1.9
    ZWNS-30 30×104 380/50 0.8 37.0 31.4 DN200 2.1
    ZWNS-40 40×104 380/50 1.0 49.4 41.8 DN200 2.4
    ZWNS-50 50×104 380/50 1.4 61.7 52.2 DN250 2.9
    ZWNS-60 60×104 380/50 1.4 74.1 62.7 DN250 3.1
    ZWNS-80 80×104 380/50 1.8 98.8 83.6 DN300 3.8
    ZWNS-100 100×104 380/50 2.6 123.4 104.5 DN300 4.5
    ZWNS-120 120×104 380/50 4.0 148.1 125.4 DN350 5.1
    ZWNS-150 150×104 80/50 5.5 185.2 156.8 DN400 7.1
    ZWNS-180 180×104 380/50 6.5 222.2 188.1 DN450 7.8
    ZWNS-200 200×104 380/50 6.5 246.9 209.1 DN450 8.3
    ZWNS-240 240×104 380/50 6.5 296.3 250.8 DN500 9.9
    ZWNS-300 300×104 380/50 9.0 370.3 313 DN550 13.4
    ZWNS-360 360×104 380/50 10.5 444.3 376.2 DN600 17.2
    ZWNS-480 480×104 380/50 25 592.5 - DN700 24.4
    ZWNS-600 600×104 380/50 25 740.6 - DN800 28.7
    ZWNS-900 900×104 380/50 45 1111 - DN900 46.5
    ZWNS-1200 1200×104 380/50 55 1481 - 1200 57.8




    china boiler manufacturer ZWNS type fire tube gas fired water boilerchina boiler manufacturer ZWNS type fire tube gas fired water boiler

    Guarantee: One-year warranty and full-life service for all of our steam boilers;

    A full range of original spare parts are available for all YINCHEN boilers

    Pre-sales Service: Based on customers’ request and budget, our experts make efficient, reliable

    solutions, and we produce strictly following customers’ order. Every customer has the chance to visit

    our workshops before placing the order. And we help to arrange cars, hotels, and the translators for

    every visiting customer.

    After-sales Service: Experienced technicians guidance is available on the phone, and on the internet.

    One or more engineers will be dispatched to the installation site to help install the customers’ boilers.

    We also provide necessary training about boiler operation and daily maintenance to local workers.



    PACKING AND SHIPPING

    Packaging Standard Export Package:Regular packing or nude packing.
    Transportation By land or by sea, depended on the exporting area.

    FAQ

    • QWhat is your patment term ?
    • AUsually it would be 30% deposit payment, 70% balance before delivery.  T/T, L/C and other way.
    • QAre your company is a trading company or a factory?
    • AWe are a 20 years old industrial boiler factory, specializing in OIL and GAS and Coal fired steam boiler.
    • QWhat is the warranty for boilers?
    • AOur company promises all the accessories can be changed for new ones because of quality problems within 3 years, and the boiler host has Lifetime Warranty.
    •
    • QCan we get installation and commissioning service ?
    • AYes, our engineers are available for your need, but the relative cost needs to be paid.
    • QWhat about the delivery ?
    • AUsually it will take about 35-45 days for pressured boilers, and 25-30 days for non-pressured boilers. Double confirmation shall be necessary before ordering.
    •
    • QWhere is your company or your factory?
    • AOur factory is located in Taikang County Industry Cluster, Henan Province, China.
    • QWhat’s your MOQ?
    • AOnly 1 set, if you have more than that, you will get a more favorable price.
    • QCan we visit your factory ?
    • AOYes, welcome for your coming at any time. If you need, we can pick you up when you get to our province.
