| Place of Origin: | HENAN |
| Brand Name: | Yinchen |
| Certification: | ISO SGS CE |
| Model Number: | WNS |
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | usd 5000-59800 set |
| Packaging Details: | 1.Package: Regular package or nut package; 2.Transportation: By land or by sea , it depends on the exporting areas. |
| Delivery Time: | 1-20 working days |
| Payment Terms: | L/C, T/T, MoneyGram |
| Supply Ability: | 5000 set month |
| Name: | 1.25Mpa Oil Fired Steam Boiler | Structure: | Fire Tube |
|---|---|---|---|
| Type: | Horizontal | Service: | Engineer Is Available To Overseas Service |
| Fuel: | Oil/ Gas | Rated Steam Temperature: | 170/184/194/204 C |
| Thermal Efficiency: | >94% | Application: | Chemical/Medical/Food/Textile Industry |
| High Light: | oil powered boiler,low pressure hot water boiler |
||
Product introduction:
Our steam boiler, using proprietary patented technology, high efficiency, energy saving, well-made, widely used in industry, selling at home and abroad.
1. Italy Battur Burner
The brand of the burner Is Italy Battur. we also use Rellio. There are gas burner, oil burner, and oil and gas duel fuel burner. The fuel could be diesel, furnace oil.
2. Sufficient Storage
Adopts the structure of horizontal tri backhauling , sufficient steam storage and heating surface make the boiler to generate bigger thermal power and high quality steam .
3. Smoke Chamber
Monolithic smoke chambers are used at the front and end , the smoke chamber door is split structure ,it is convenient for maintain , detect and clean .
4. Thread Smoke Tube
Advanced manufacturing process , adopt assembly line automatic work,strengthen heat transfer to improve boiler heat efficiency .
5. Fully Automatic Control
Fully automatic operation combustion, water level temperature and pressure are adjusted automaticlly and self protection .
6. Corrugated Furnace
This series boiler adopts whole corrugated furnace . Reinforce the disturbance of flue gas as well as improving the heat transfer efficiency of unit area and unit volume . increase the strength and elasticity of furnace prevent the pressure parts from being damaged because of the increase of stress efficiently during the the thermal expansion procedure.
| Model | Rated | Rated | Rated | Thermal |
Fuel Consumption |
Equipment Power |
Weight | ||
|
Capacity (t/h) |
Pressure (Mpa) |
Temperature (C) |
Efficiency (%) |
Light oil (Kg/h) |
Natural gas (Nm³/h) |
Oil boiler |
Gas boiler | (t) | |
| WNS1 | 1 | 0.7/1.0/1.25 | 170/184/194 | >90 | 45-100 | 18-100 | 1.5 | 1.5 | 4 |
| WNS2 | 2 | 1.0/1.25/1.6 | 184/194/204 | >90.2 | 137.09 | 165.97 | 2.2 | 3 | 8 |
| WNS3 | 3 | >91 | 205.75 | 249.6 | 7.5 | 7.5 | 9 | ||
| WNS4 | 4 | >91 | 272.3 | 329.5 | 9 | 7.5 | 13 | ||
| WNS5 | 5 | >91.5 | 134-402 | 80-500 | 15 | 15 | 15 | ||
| WNS6 | 6 | >91.5 | 134-402 | 80-500 | 17.2 | 15 | 17 | ||
| WN8 | 8 | 1.25/1.6/2.5 | 194/204/225 | >91.6 | 523.4 | 631.5 | 26 | 22 | 21 |
| WNS10 | 10 | >91.6 | 212-890 | 150-1085 | 26 | 22 | 22 | ||
| WNS12 | 12 | >91.8 | 915.5 | 1090 | 26 | 22 | 27 | ||
| WNS15 | 15 | >91.8 | 931.5 | 1094.4 | / | / | 34 | ||
| WNS20 | 20 | >92 | 1380.33 | 1598.44 | / | / | 45 | ||
| Note: This Parameter just for reference only, we can design and production as per customers’ requirements. | |||||||||
1). High efficiency
The radiation heating surface of boiler adopts corrugated furnace and the convection heating surface adopts threaded flue tube, so the heating surface is bigger than common boiler, and which directly affect the thermal efficiency up to above 95%.
2). High quality welding
Pipe plate and barrel adopt pull side connection, while the welding line of boiler body adopts butt joint structure, all these welding uses unionmelt welding to ensure welding quality and flaw detection rate up to 100%.
3). PLC intelligent control system
Our boiler adopts the integrated control equipment and PLC (PLC) control system, and operating the control system through touch screen increased greatly the automation degree and reliability, more easy to operate.
4). Advanced structure and environment friendly
Adopting wet back three return structure, corrugated furnace and thread pipe structure has good thermal scalability. Reasonable chamber design is suitable for various fuel, such as heavy oil, light oil, natural gas, coal gas, etc., and the fuel burns fully inside chamber as well as the flue gas pollutant is small, accord with state environmental protection requirements.
5). High quality auxiliary
The boiler adopts internationally renowned brand burner, such as Riello, Paterson, and the auxiliary instrument & valve also adopt famous brand, such as Siemens, Schneider, Omron, etc., to ensure boiler quality and safety.
6). Beautiful appearance
The boiler appearance uses colorful steel plate and the surface adopts high temperature paint and makes appearance perfect and beautiful.
7). Save space
Adopting package structure, the whole set boiler is set on the foundation with good quality, easy to install and transport, and save space for boiler room.
8). Safety and stable
Setting various protect function for boiler, such as over-temperature, over-pressure, water shortage, water level detectors and other, etc., to ensure boiler working safe and reliable.
| Packaging | Standard Export Package:Regular packing or nude packing. |
| Transportation | By land or by sea, depended on the exporting area. |
